It is used to blow various plastic film of low density polyethylene(LDPE), high density polyethylene(HDPE) and linear low density polyethylene(LLDPE), etc.. Widely used in packing food stuff, garment and textile, daily product, industrial products and agricultural field.
| model | thickness | film width | max output | screw diameter | L/D ratio | temp. controller | barrel cooling | drivffing motor | die diameter |
| FM-1100 | 0.02--0.20mm | 1000mm | 90kgs/hr | Φ55mm | 30:1 | 5 zone | 120w*2 | 30kw | Φ200mm |
| air ring diameter | cooling fan | take up width | effective take up width | take up motor | winder width | effective winder width | winder motor | suitable material |
| Φ300mm | 2.2kw | 1100mm | 1000mm | 1.5kw | 1100mm | 1000mm | 1.5kw | LDPE/LLDPE/HDPE |
| die structure | spiral mandrel die chrome plated surface 40Cr |
| optional equipment | auto-loader device, film surface treater, air compressor, fast change net, double center winder/cage roll flat winder, rotary die head, double wind air ring |
