Applicable for the materials such as LDPE,LLDPE,HDPE,EVA,EAA etc.. It is widely used in high-quality plasticpacking film like basic material for composited film, liquid film, shrink film and industrial package etc..
| Model | FM-2200 | FM-2600 | FM-3200 | FM-3800 | FM-4300 |
| suitable material | LDPE/LLDPE/HDPE/MLLDPE/EVA/EAA etc. |
| film width | 2100mm | 2500mm | 3000mm | 3700mm | 4200mm |
| thickness | 0.01--0.16mm |
| screw diameter | Φ105mm*1 | Φ120mm*1 | Φ135mm*1/Φ90mm*2 | Φ145mm*1/Φ95mm*2 | Φ155mm*1/Φ120mm*2 |
| L/D ratio | 30:1 |
| die diameter | Φ550mm | Φ650mm | Φ750mm | Φ800mm | Φ1100mm |
| die structure | Spiral mandrel die chrome plated surface 40Cr |
| main power | 55kw | 75kw | 90kw*1 / 45kw*2 | 130kw*1 / 55kw*2 | 160kw*1 / 75kw*2 |
| max output | 260kg/h | 330kg/h | 380kg/h | 450kg/h | 650kg/h |
| winder way | Torque motor winder |
| optional equipment | auto-loader device, film surface treater, air compressor, fast change net, double center rewinder/auto rewinder, flat cage roll winder, rotary die head, double wind air ring. |
