It is used to blow various plastic film of low density polyethylene(LDPE), high density polyethylene(HDPE) and linear low density polyethylene(LLDPE), etc.. Widely used in packing food stuff, garment, textile, daily product, industrial produdcts and agricultural field.
| Model | suitable material | thickness | film width | max output | screw diameter | L/D ratio | temp. controller | barrel cooling | driving motor |
| FM-3200 | LLDPE/LDPE/HDPE | 0.02--0.20mm | 3000mm | 380kd/h | Φ135mm | 30:1 | 8 zone | 250w*4 | 75kw |
| die diameter | air ring diameter | die structure | cooling fan | draging width | effective draging width | draging motor | winder width | effective winder width | winder motor |
| Φ750mm | Φ1100mm | spiral mandrel die chrome plated surface 40Cr | 7.5kw | 3200mm | 3000mm | 3.7kw | 3200mm | 3000mm | 160kg |
| optional equipment | auto-loader device, film surface treater, air compressor, fast change net, double center winder/automatic winder, flat cage roll winder, rotary die head, double wind air ring |
