Widely used in compound film, insulated film and all kinds of agriultural film field.
| model | suitable material | thickness | film width | max output | screw diameter | L/D ratio | temp. controller | barrel cooling | driving motor |
| FM3-1700 | PE | 0.02-0.20mm | 1500mm | 150kgs/hr | Φ65mm*2 | 30:1 | 12 zone | 120w*4 | 22kw*2 |
| die diameter | air ring diameter | cooling fan | draging width | effective draging width | draging motor | winder width | effective winder width | winder motor |
| Φ350mm | Φ450mm | 3kw | 1700mm | 1600mm | 2.2kw | 1700mm | 1600mm | 50kg |
| die structure | spiral mandrel die chrome plated surface 40Cr |
| optional equipment | auto-loader device, film surface treater, air compressor, fast change net, double center winder/cage roll flat winder, rotary die head, double wind air ring |
